Teardrop Camping Trailer Wiring Manual

Teardrop Trailer Frame & Body – Wiring Plans

$35.00

Electrical for your teardrop trailer will last a long time with these wiring plans.



There is no frustration greater than having the tow vehicle loaded up, everyone buckled up, and then discover that your tail lights, side markers, or blinkers aren’t working.  Or the lights don’t work when you turn it on at night.

Duplicate manufacturer wiring plans wiring that lasts the test of time minimal maintenance!

Do your trailer wiring ONCE and do it RIGHT!  These plans are videos, pictures, schematics, tool lists, upgrade options, and everything you need to have trailer lights last 10+ years with little to no maintenance.

Get these plans and get on the road knowing that your wiring is reliable and long-lasting.

Availability: In stock (can be backordered)

Shipping Calculated at Checkout

  • Put the Item(s) you want in the shopping cart
  • Enter Your Delivery Address
  • Least Expensive Shipping (USPS or UPS) is Calculated
Guaranteed Safe Checkout

The Overland Teardrop Trailer – Detailed Wiring Plans without a lot of fuss!

Most teardrop trailer frame wiring is made from cheap components and is based on a poor plan.

These plans teach you about the qualities of materials needed to make long-lasting trailer frame wiring, the methods for installation that is fast and saves on material costs, and the tools that make this installation solid, fast, and easy on the body.

These trailer frame & body plans use a standard 7-blade RV wiring connector because it offers a durable connection and additional options for the teardrop trailer builder who may want to add a few extras to their trailer.  Easily add backup lights and 12V charging to the trailer battery from the tow vehicle’s electrical system.

Included in this Full-Color Printed Plan:

  1. Trailer Frame & Body Wiring Schematic
  2. Breakdown of all required Parts
  3. Wire types & Lengths
  4. Connection Types
  5. Installation tools
  6. How-To Videos
  7. Photos of the process
  8. Wire Management tips for a long-lasting installation.
Weight 6 lbs
